VR SHINECON Original 6.0 VR Headset Instruction Manual

Kupu Whakataki

The VR SHINECON Original 6.0 VR Headset provides an immersive 3D experience for movies and games. Its portable design allows for comfortable use anywhere, transforming your smartphone into a virtual reality viewer. This manual will guide you through the setup, operation, and maintenance of your VR headset.

Ihirangi mokete

Upon opening your VR SHINECON package, you should find the following items:

• VR SHINECON Original 6.0 VR Headset with integrated headphones
• Bluetooth Remote Controller (requires 2x AAA batteries, not included)
• Kaka horoi
• Pukapuka Kaiwhakamahi
• Lightning to 3.5mm Headphone Jack Adapter (for iPhone users)
• Spacer (removable, for phone size adjustment)

Tatūnga

1. Te whakauru i to Waea atamai

1. Open the front compartment of the VR headset.
2. If your phone is smaller, you may use the included spacer for a snug fit. For larger phones (4.7-7.2 inches), the spacer can be removed.
3. Place your smartphone onto the ledge inside the compartment, ensuring it is centered. The internal cushions will help secure the phone.
4. Close the front compartment securely.

Image: The VR SHINECON headset with a smartphone inserted, illustrating its compatibility with phones ranging from 5.5 to 7.2 inches.

Whakaahua: He taipitopito view of the VR SHINECON headset's HD eye protection lenses.

2. Hononga Ororongo

• Locate the headphone jack cable on the side of the VR headset.
• Plug this cable into your smartphone's 3.5mm headphone jack.
• If your iPhone does not have a 3.5mm jack, use the provided Lightning to 3.5mm adapter. Note that an adapter for Android phones (USB-C to 3.5mm) is not included.

3. Pairing the Bluetooth Remote Controller

1. Insert two AAA batteries into the Bluetooth remote controller (batteries not included).
2. Press and hold the power button on the controller until the indicator light starts blinking.
3. On your smartphone, go to Bluetooth settings and pair with the controller.
4. Tuhipoka: The remote controller is primarily designed for Android devices. Its functionality with iOS devices may be limited, mainly supporting iCade VR/non-VR games, video/music playback, camera shutter, e-book page flipping, and volume adjustment. Full remote control functions are available in VR games on Android.

Image: The Bluetooth remote controller in Game Mode, detailing button functions for both Android and iOS.

Image: The Bluetooth remote controller in Key Mode, illustrating its use for mouse operation, selfie functions, and media control.

Mahi

1. Te whakatikatika i te Paneoro

• Place the headset on your head. Adjust the velcro straps on the top and sides for a secure and comfortable fit.
• Adjust the integrated headphones to align with your ears. The ear cups can be pulled back and adjusted.
• Glasses Compatibility: The headset is designed to accommodate most eyeglasses. Adjust the headset carefully to ensure comfort and clear vision.

Image: The VR SHINECON headset is designed to be worn comfortably over eyeglasses.

2. Focus and Interpupillary Distance (IPD) Adjustment

• Use the two focus wheels located on the top of the headset to move the lenses forward or backward until the image is clear for your vision.
• Adjust the dial in the middle of the headset to change the spacing between the lenses (IPD). This ensures that your eyes align correctly with the lenses, providing a single, clear image without a black bar in the middle or double vision.

3. Using the Touch Control Button

• The touch control button is located on the bottom of the headset. This button simulates a screen tap.
• In compatible VR applications, you can use this button to select items or interact with the virtual environment without removing your phone.

4. Hototahitanga Taupānga

• The VR SHINECON headset is compatible with VR Cardboard-type applications.
• Before inserting your phone, ensure you have launched the desired VR application.
• Explore various VR apps available on your smartphone's app store (Google Play Store for Android, Apple App Store for iOS) to find content compatible with this headset.
• Tuhipoka: Apps designed for specific VR platforms like Oculus may not function with this headset.

Image: Experience a wide 100-degree field of view, enhancing immersion in virtual environments.

Image: Users enjoying an immersive virtual reality experience, such as a roller coaster ride.

Te tiaki

• Whakapai Arotahi: Use the provided cleaning cloth to gently wipe the lenses. Avoid using abrasive materials or harsh chemicals that could scratch or damage the lenses.
• Te horoi i te pane whakarongo: Wipe the exterior of the headset with a soft, dry cloth.
• Rokiroki: Penapenahia te pane whakarongo ki te wāhi hauhautanga, maroke, kia matara atu i te rā tika me te puehu ina kore e whakamahia.

Raparongoā

• Blurred or Double Vision:
  • Adjust the focus wheels on top of the headset until the image is clear.
  • Adjust the central dial to fine-tune the interpupillary distance (IPD) for a single, unified image.
• Bluetooth Controller Not Connecting/Working:
  • Ensure the controller has fresh AAA batteries.
  • Verify Bluetooth is enabled on your smartphone and the controller is in pairing mode.
  • Restart both your phone and the controller, then attempt to re-pair.
  • Remember that controller functionality can vary significantly between different VR applications, especially on iOS devices.
• Kore Ororongo:
  • Ensure the headset's audio cable is securely plugged into your phone's headphone jack or the appropriate adapter.
  • Tirohia nga tautuhinga rōrahi o to waea.
• Kāore te Waea e Taunga:
  • Ensure your phone's screen size is within the supported range of 4.7-7.2 inches.
  • Adjust or remove the internal spacer as needed to accommodate your phone's dimensions.

Whakatakotoranga

Pūtāhui me te Tautoko

For any questions, technical support, or warranty inquiries regarding your VR SHINECON Original 6.0 VR Headset, please contact the seller or manufacturer directly. Refer to your purchase documentation for specific warranty terms and contact information.

If you require a USB-C to 3.5mm female adapter for your Android phone, please contact the seller for assistance.
