1. Kupu Whakataki
This manual provides essential instructions for the safe and efficient operation, installation, and maintenance of your SHARP AH-XP12WMT INV Inverter Split Air Conditioner. Please read this manual thoroughly before using the appliance and retain it for future reference.
The SHARP AH-XP12WMT INV is a 1 Ton Inverter Split AC designed to provide a comfortable indoor environment. It features a copper condenser and a dust filter for enhanced performance and air quality.
Image: SHARP AH-XP12WMT INV Indoor Unit. This image shows the overall appearance of the air conditioner's indoor unit.
2. Tatūnga me te Tāuta
Proper installation is crucial for the optimal performance and longevity of your air conditioner. It is highly recommended that installation be performed by a qualified and certified technician.
2.1 Te Wetewete
Carefully unpack all components. Ensure all parts are present and undamaged. The package includes the indoor unit, outdoor unit, remote control, and a hose.
2.2 Ngā Whakaaro mō te Tūnga
The indoor unit (IDU) dimensions are 87.70 cm (Width) x 22.20 cm (Depth) x 29.20 cm (Height). Ensure adequate space for air circulation and maintenance.
Image: Indoor Unit Dimensions. This diagram illustrates the physical measurements of the indoor unit, crucial for planning installation space.
2.3 Hononga Hiko
The unit operates on 230 Volts. Ensure the electrical supply meets the requirements and a dedicated circuit is used. All electrical work must comply with local codes and regulations.
3. Nga Tohutohu Whakahaere
Your SHARP AC AH-XP12WMT INV is controlled via a remote control. Familiarize yourself with the remote's functions for optimal use.
3.1 Mahi Taketake
- Hiko Whakaka/Weto: Pēhia te pātene hiko i te mana mamao hei whakakā, whakaweto rānei i te kōwae.
- Te Whakarerekenga Pawera: Whakamahia ngā pātene whakarunga/whakaheke pāmahana hei whakarite i te pāmahana rūma e hiahiatia ana.
- Kōwhiringa Aratau: Select operating modes such as Cool, Fan, Dry, or Auto using the mode button.
- Tere Kiri: Adjust the fan speed to your preference (Low, Medium, High, Auto).
3.2 Nga waahanga motuhake
- Follow Me Sensor Mode: This feature allows the remote control to act as a thermostat, sensing the temperature at its location and adjusting the AC operation to maintain the desired temperature around you.
- Tātari Puehu: The integrated dust filter helps improve indoor air quality by trapping airborne particles.
4. Tiaki
Ko te tiaki i nga wa katoa ka pai te mahi me te whakaroa i te oranga o to hau.
4.1 Tātari Tātari
The dust filter should be cleaned regularly, typically every two weeks or more often depending on usage and air quality. To clean:
- Whakawetohia te hau hau ka momotu te mana.
- Whakatuwherahia te papa o mua o te waahanga o roto.
- Tangohia nga whiriwhiringa hau.
- Horoihia nga whiriwhiringa ki te miihini horoi horoi ranei ki te wai maama me te horoi ngawari.
- Tukuna kia maroke katoa nga whiriwhiringa i mua i te whakauru ano.
- Katia te papa o mua.
4.2 Whakapai Whanui
Horoia te taha o waho o te whare o roto, o waho hoki ki te ngohengohe, damp cloth. Do not use harsh chemicals or abrasive cleaners. Ensure the outdoor unit's coils are free from debris.
5. Te Raru
I mua i te whakapā atu ki te ratonga, review these common issues and solutions.
- Karekau te waeine e ka ana: Check power supply, circuit breaker, and remote control batteries.
- He iti rawa te whakamatao: Ensure doors and windows are closed. Clean air filters. Check for obstructions to airflow. Adjust temperature setting.
- Haruru rereke: Minor operational noises are normal. If noise is excessive or unusual, turn off the unit and contact service.
- Te rerenga wai: Check if the drain hose is blocked or improperly installed.
For persistent problems or issues not listed here, contact a qualified service technician.
6. Whakatakotoranga
Key technical specifications for the SHARP AH-XP12WMT INV Air Conditioner:
Image: Product Features Summary. This infographic highlights the main characteristics and benefits of the air conditioner.
| Āhuahira | Whakatakotoranga |
|---|---|
| Waitohu | KOI |
| Tauira | AH-XP12WMT INV |
| Nama Wahi | 91001829 |
| Te kaha | 1 Toni |
| Te Whakamahi Pungao a-Tau | 719 Kirowatt |
| Taumata Haruru | 52 Decibels |
| Momo Tāuta | Ritua Pūnaha |
| Nga waahanga motuhake | Dust Filter, Follow Me Sensor Mode |
| Tae | Mā |
| Papatohu Mana | Mana Mamao |
| Voltage | 230 Volts |
| Wattage | 3520 KW |
| Tiwhikete | Whetu Pungao |
| Rauemi | Te parahi |
| Nga Waahanga kei roto | Te ngongo |
| Product Dimensions (IDU) | 22.2D x 87.7W x 29.2H Henemita |
| BEE Whetu Whakatauranga | 3 Whetu |
| Approximate Coverage Area | 130 Sq. Ft (12.07 Sq. M) |
7. Pūtāhui me te Tautoko
For warranty information and technical support, please refer to the warranty card included with your product or contact SHARP customer service directly. Keep your purchase receipt as proof of purchase for warranty claims.
Kaihanga: SHARP
Date First Available: 23 April 2021
