Kupu Whakataki
This manual provides essential information for the safe and efficient use of your Volkano Valencia Series Ladies Smart Watch. Please read these instructions carefully before using the device and retain them for future reference.
He aha kei roto i te Pouaka
- Volkano Valencia Series Smart Watch (VK-5050-GD)
- Tauranga Waea Ahokore
- Pukapuka Kaiwhakamahi
Ka mutu te huaview
The Volkano Valencia Series Smart Watch features a 1.32" AMOLED touchscreen display and a metal mesh strap. It offers various functionalities including Bluetooth wireless calling, health tracking, multi-sport modes, and smart notifications.
Atahanga: Mua view of the Volkano Valencia Smart Watch, showing the circular AMOLED display with digital time, heart rate, and step count. The rose gold metal mesh strap is visible.
Atahanga: Whakamuri view of the Volkano Valencia Smart Watch, highlighting the optical heart rate and blood oxygen sensors, along with the wireless charging contacts. The model number VK-5050 is visible.
Tatūnga
1. Ka utu i te Mataara Ataata
Before first use, fully charge the smart watch. Place the watch onto the included wireless charging dock. Ensure the charging contacts on the watch align with the dock. The watch display will indicate charging status. A full charge typically takes approximately 2 hours.
2. Te Hiko / Whakaweto
- Whakahiko: Press and hold the side button for a few seconds until the Volkano logo appears.
- Weto Whakakore: Patohia me te pupuri i te paatene taha, ka kowhiri i te kōwhiringa 'Power Off' i runga i te mata.
3. Whakahoahoa ki to Waea atamai
- Download the companion application from your smartphone's app store (compatible with Android 5.1+ and iOS 8.0+).
- Me mohio kei te whakahohea te Nihokikorangi i runga i to waea atamai.
- Open the application and follow the on-screen instructions to add your device.
- Select "VK-5050-GD" or a similar device name from the list of available Bluetooth devices in the app.
- Whakaūhia te tono takirua i runga i to mataaratanga me to waea atamai.
Nga Tohutohu Whakahaere
1. Whakaterenga Taketake
- Mata pa: Swipe mauī/matau, whakarunga/iho ki te whakatere i roto i nga tahua me nga ahuatanga. Patohia hei kowhiri.
- Pātene taha: Pēhia kia hoki ki te mata o te kāinga, whakaohooho ranei i te whakaaturanga.
2. Bluetooth Wireless Calling
Kia honoa ki tō waea atamai, ka taea e koe te waea atu me te whiwhi waea tika mai i tō mataaratanga.
- Waeatanga: Access the dialer or contact list on your watch.
- Whiwhi Waea: Ka puta he panui waea taumai i runga i te mataaratanga. Patohia ki te whakautu, ki te whakaheke ranei.
3. Kaiāwhina Reo Whakauru-ā-roto
Activate the voice assistant feature on your watch to perform tasks such as setting reminders, checking weather, or controlling music using voice commands.
4. Whakamōhiotanga Maamaa
Receive real-time alerts for calls, messages, emails, and app notifications directly on your wrist. Ensure notification permissions are enabled in your smartphone's settings and the companion app.
5. Remote Camera & Music Control
- Mana Kamera: Open the camera function in the companion app on your phone, then use your watch as a remote shutter button.
- Mana Waiata: Control playback (play/pause, skip tracks) of music playing on your smartphone through the watch's music control interface.
6. Aroturuki Hauora
The watch monitors various health metrics:
- Aroturuki Reiti Manawa: Provides continuous or on-demand heart rate readings.
- Aroturuki Hauora Toto: Ka ine i nga taumata o te hau o te toto.
- Patohanga: Tracks daily steps taken.
- Aroturuki Calorie: Ka whakatau tata i ngā kaora i tahuna i runga i te mahi.
For accurate readings, ensure the watch is worn snugly on your wrist, approximately one finger-width above the wrist bone.
7. Ngā Aratau Hākinakina Maha
The watch supports over 100 multi-sport modes to track various physical activities. Select the desired sport mode from the watch menu to record specific workout data.
8. Ātete Wai (3 ATM)
The watch is rated 3 ATM water-resistant, meaning it is protected from splashes such as rain or hand washing. It is kaore suitable for immersion in water, swimming, or sauna use.
Atahanga: A woman smiling, wearing the Volkano Valencia Smart Watch on her left wrist. The watch features a rose gold finish and a metal mesh strap.
Te tiaki
1. Te horoi
Wipe the watch screen and body with a soft, dry, lint-free cloth. For the strap, use a slightly damp cloth if necessary, then dry thoroughly. Avoid using harsh chemicals or abrasive materials.
2. Tiaki Pūhiko
To prolong battery life, avoid fully discharging the watch frequently. Charge the watch regularly, especially if it will not be used for an extended period. Store in a cool, dry place.
3. Nga Aratohu Atete Wai
Adhere strictly to the 3 ATM water resistance rating. Do not immerse the watch in water, expose it to high-pressure water jets, or use it in saunas or steam rooms. Water damage due to improper use is not covered under warranty.
Raparongoā
- Kia mataara kia kaua e huri: Ensure the watch is fully charged. Connect it to the wireless charging dock for at least 30 minutes.
- Kaore e taea te hono ki te waea atamai:
- Me mohio kei te whakahohea te Nihokikorangi ki to waea.
- Me mohio kei roto te mataaratanga i te awhe Nihokikorangi (te tikanga 10 mita).
- Tīmatahia te mataaratanga me to waea atamai.
- Check if the companion app has necessary permissions.
- Raraunga hauora hē: Ensure the watch is worn correctly, snugly on the wrist, and the sensors are clean. Avoid excessive movement during measurements.
- Ko nga whakamohiotanga kaore e puta: Verify that notifications are enabled in both your phone's settings and the companion application. Ensure the watch is connected via Bluetooth.
Whakatakotoranga
| Tau tauira | VK-5050-GD |
| Putanga Nihokikorangi | 5.3 Low Energy (JL7012 Chipset) |
| Whakaatu | 1.32" Mata Paa AMOLED |
| Maharahara | 640KB RAM + 128Mb Flash Storage |
| Pūhiko | 230mAh (2-3 days active use / up to 15 days standby) |
| Te utu | Wireless Dock Included |
| Hototahi | Android 5.1+ | iOS 8.0+ |
| Ātete wai | 3 ATM (Splash-proof, not for immersion) |
| Tae | Rose Koura |
Pūtāhui me te Tautoko
Pūtāhui a te Kaihanga
This Volkano product is covered by a 1-tau iti pūtāhui from the date of purchase. This warranty covers manufacturing defects and workmanship under normal use. Damage resulting from misuse, accidents, unauthorized modifications, or failure to follow instructions is not covered.
You may be eligible for an additional 12-month extension to your warranty, totaling 24 months of coverage, by registering your product. Please refer to the Volkano official website or product packaging for registration details.
Tautoko Kiritaki
For technical assistance, troubleshooting, or warranty claims, please contact Volkano customer support. Refer to the contact information provided on the official Volkano webte pae, to putunga hua ranei.
